  • OCLARO奥兰若 波长可调激光器 50GHz间隔 C波段 TL5000

OCLARO奥兰若 波长可调激光器 50GHz间隔 C波段 TL5000

50GHz波长间隔可调, C或L波段ITU标准波长, 1528.77nm~1563.86nm共89通道; 也有96通道可选; 保偏光纤20mW典型输出, 典型1MHz窄线宽, 低强度噪声, 高边模抑制比, 高波长稳定性及功率稳定性, 10mS波长切换速度, 小尺寸组件封装, RS232协议接口.

产品详情

该高性能波长可调激光器组件, 波长覆盖C或L波段的ITU Grid, C波段典型1528.77nm~1563.86nm共89通道, 并提供96通道规格可选. 基于OIF iTLA标准, 该组件电路板上集成了激光和控制元件, 通过RS232协议接口可对激光器的波长调谐, 光功率可变等工作状态及参数进行设置. 具有高达20mW连续光输出, 1MHz典型窄线宽, 低强度噪声, 高边模抑制比, 高波长稳定性及功率稳定性, 10mS波长切换速度, 紧凑型小尺寸组件封装. 非常适合作为40G/100Gbpcs的长距离高速光纤通信系统的光源, 以及C波段的DWDM光无源器件和光电探测器的测试及测量.

Oclaro TL5000 Series, 50GHz 89CH or 96CH DWDM Tunable Laser Source Module, ITLA

The Oclaro Lambda FLEXTM iTLA is a high performance continuous wave (CW) tunable laser source for use in the C-band window covering 1528nm to 1563nm. Based on the OIF iTLA standard, the laser and control electronics are pre-mounted on a dedicated circuit board for easy production installation. The iTLA features variable power, shuttered tuning, trace tone and FM dither circuitry. Comprehensive control and system reporting is provided over the RS232 interface.

The iTLA implements the Oclaro DSDBR wideband tunable laser. This laser is a fully monolithic InP chip designed for high volume, low cost manufacturing. With no moving parts, it is a low voltage electronically tuned device enabling rapid wavelength switching with straightforward control electronics. The integrated semiconductor optical amplifier (SOA) provisions the optical power control and also acts as a shutter to allow dark tuning when reverse biased.

Laser chip operation is at a fixed temperature. Wavelength stability is guaranteed by an internal wavelength locker for control to a 50GHz or 100GHz ITU wavelength grid. Front facet output power monitoring is also provided by the wavelength locker for feedback control through the SOA. The device is provided with polarization maintaining fibre for use with an external modulator.

Features:

• Full C-Band tunable source (1528-1563nm) based on OIF iTLA footprint

• High power +13dBm EOL

• High speed electronic tuning control (<10ms channel to channel)

• Electronic shutter for dark tuning

• Low power dissipation, 3.8W typical

• Narrow line-width, 5MHz maximum

• Excellent SMSR >40dB

• Low RIN

• Wavelength stabilized for 50GHz or 100GHz ITU-T channel spacing

• Optical power monitor

• FM Dither / Trace tone capability

• Case operating temperature range -5ºC to +75ºC

• Simple RS232 interface

• RoHS compliant

• Telcordia Qualified to GR 468

Applications:

• Long Haul/Ultra Long Haul

• Regional Metro

• Test and Measurement
