10Gbps强度调制速率, SMA射频口. 低于4.0dB超低插入损耗, 消光比30dB, 35dB, 40dB可选, 低驱动电压, 零啁啾. 适合光脉冲产生与检测, 载波抑制, 光纤传感等应用.
DESCRIPTION
The Photline MXER-LN series of intensity modulators is a family of high performance modulators exhibiting superior Extinction Ratio. Their specific design relies on Ixblue “Magic Junction” (patent n° US2008193077). MXER-LN series intensity modulators are key devices in all applications where a combination of high extinction and high bandwidth is required: laser pulse picking prior optical amplification, pulse generation or lidar based sensing systems are a few examples, as well as fiber optics sensors.
FEATURE
• Superior extinction ratio: 40 dB
• High bandwidth
• X-cut for high stability
• Low drive voltage
• Low insertion loss
APPLICATION
• Pulse generation / picking
• Carrier suppression
• Fiber optics sensors
• Pulse applications
ORDER INFORMATION
MXER-LN-BW-XX-Y-Z-AB-CD-xxdB
BW = Bandwidth : 10 10 GHz 20 20 GHz
XX = Internal photodiode PD, 00 : Not integrated PD : Integrated
Y = Input fiber : P Polarization maintaining S Standard single mode
Z = Output fiber : P Polarization maintaining S Standard single mode
AB = Input connector : 00 bare fiber FA FC/APC FC FC/SPC
CD = Output connector : 00 bare fiber FA FC/APC FC FC/SPC
xxdB = Extinction ratio : 30 30 dB – 35 35dB – 40 40dB
Note : optical connectors are Senko with narrow key or equivalent
