PC1300自动偏振控制器是被用来远程控制和手动调试其偏振态的设备。光纤四分之一波长的波片被马达驱动。既可以通过带模拟电压输入的远程控制，也可以通过RS232远程控制旋转波片的角度位置。自动偏振控制器还提供传统的“保存和记忆”的功能，它也提供自动扫描模式和的可变扫描速度。其低插损（低于0.5dB）和高消光比。它具有超紧凑的结构，便于内置于系统中。
产品特点描述
– 全光纤结构
– 低回扰
– 高消光比
– 自动全范围扫描
– 低插损
– 超小尺寸
– 带模拟电压输入的远程控制
– RS232远程控制
PC1300 is designed to manipulate the polarization states by either manual adjustment or remote control. Fiber optic quarter-wave plates are driven by motors.
Either by applying analog voltage or by RS232 control, you can remotely control the angular positions of the wave plates. The MPC offers convenient “save and recall” functions with built-in memory. It also provides “auto scan” mode at variable scanning speeds with low insertion loss (less than 0.5 dB) and high polarization extinction ratio. Its compact size enables the MPC to be installed on an electric circuit board.
Features
All-fiber configuration
Low Back Reflection
High Extinction Ratio
Automatic Full Range Scan
Low Insertion Loss
Compact Size
Remote Control with analog voltage input
RS232 Remote Control
