  • 1:4电域解复用器, 40Gbps, Centellax MD1S4V1M, Agilent N4983A-D40

1:4电域解复用器, 40Gbps, Centellax MD1S4V1M, Agilent N4983A-D40

The MD1S4V1M is a 1:4 demultiplexer. The module accepts input data rates from 2.6 to 44 Gb/s with an input sensitivity less than 200mV-se. Differential data inputs are DC coupled and terminated with 50 ohm resistors to minimize reflections. The single-ended, half rate clock input is AC coupled and operates with low input power. The module features single-ended AC coupled outputs with ECL compatible signal levels. Data outputs, clock input, and high-speed inputs are accessed via high quality 2.9mm (K) connectors. (Contact us for more information on MD1S4V2M, 56Gbps broadband DEMUX )

产品详情

40Gbps 1:4 Demultiplexer Module, Centellax MD1S4V1M, Agilent N4983A-D40

The MD1S4V1M is a 1:4 demultiplexer. The module accepts input data rates from 2.6 to 44 Gb/s with an input sensitivity less than 200mV-se. Differential data inputs are DC coupled and terminated with 50 ohm resistors to minimize reflections. The single-ended, half rate clock input is AC coupled and operates with low input power. The module features single-ended AC coupled outputs with ECL compatible signal levels. Data outputs, clock input, and high-speed inputs are accessed via high quality 2.9mm (K) connectors. (Contact us for more information on MD1S4V2M, 56Gbps broadband DEMUX )

Features

  • Half rate clock
  • High Input Sensitivity
  • Wide Operating Range, 2.6-44 Gb/s
  • Low Output Jitter
  • Low Power Consumption
  • Fast Output Rise/Fall Times

Applications

The MD1S4V1M can be used in SONET/SDH applications operating at transmission speeds within the demuliplexer’s 2.6-44Gb/s input rate. Broadband test systems will benefit from the low power dissipation, precision connectors, and excellent output waveform characteristics. The compact size of the module allows the MD1S4V1M to be placed at the measurement plane, reducing or eliminating artifacts related to long cables.
